Quick Turn Double-Sided PCB Service for Prototype Builds
Images
General Specification:
Layers: 2L
Base material: High Frequency(Rogers, ISOLA)
Copper thickness: 35um
Board thickness: 1.6mm
Minimum hole size: 0.25mm
Minimum line width: 0.3mm
Minimum line spacing: 0.15mm
Surface finish: OSP
Compliant with UL and RoHS standards
This product is a quick turn double-sided PCB service for projects that need fast prototype or short-run board fabrication. For urgent PCB builds, the actual schedule should be confirmed against design complexity, material availability, process requirements, and production queue before ordering.
Quick turn PCB work is most useful when the design files are complete and the board structure is not waiting for major engineering changes. Gerber files, drill data, board outline, material, copper thickness, solder mask, surface finish, and quantity should be ready before quotation.
Fast Prototype PCB Review
Fast PCB fabrication depends on file clarity as much as factory speed. A double-sided PCB with complete Gerber and drill files can usually be reviewed more quickly than a project with missing layer naming, unclear board outline, or incomplete finish requirements.
If the board later moves from prototype to small or medium volume, the early prototype files should already reflect the intended material, surface finish, and assembly constraints. For general rigid PCB context, see the PTH board category.
Application Fit
Quick turn double-sided PCB service is suitable for engineering samples, proof-of-concept builds, control boards, interface boards, and fast validation projects where the customer needs manufactured boards before moving to a larger production batch.
What to Confirm Before Production
Before production, confirm whether the project is prototype-only or intended for later volume production, and provide clear fabrication notes. Any special requirement such as controlled impedance, non-standard material, tight tolerance, special surface finish, or assembly deadline should be stated before the quote is finalized.
Custom Quick Turn PCB Quotation
For quotation and manufacturability review, provide Gerber files, drill files, and board outline, material requirement, copper thickness, solder mask and silkscreen colors, surface finish, quantity, and expected delivery target. For file preparation questions, see the FAQ on design and technical issues.
